What is the purpose of capacitor in a motor ?

Purpose of Capacitor in a Motor:

Capacitors play a crucial role in the operation of certain types of motors, particularly single-phase induction motors. The primary purpose of a capacitor in a motor is to create a phase shift in the current flowing through the motor windings, enabling the motor to generate a rotating magnetic field necessary for its proper functioning. Here’s a detailed explanation of the purposes and functions of capacitors in motors:

1. Single-Phase Motor Operation:

  • Single-phase induction motors are commonly used in various applications, but they face a challenge due to the absence of a rotating magnetic field in the stator, which is essential for motor rotation. Unlike three-phase motors, single-phase motors have only a single alternating current (AC) power supply, and this single-phase power alone cannot create a rotating magnetic field.

2. Starting Winding and Main Winding:

  • Single-phase induction motors typically have two windings: a main winding and a starting winding. The starting winding is responsible for initiating the motor rotation during startup, but it alone cannot sustain continuous rotation. The main winding is used to generate a rotating magnetic field during normal operation.

3. Phase Shift and Rotating Magnetic Field:

  • To create a rotating magnetic field in the main winding, a phase shift between the currents in the starting and main windings is necessary. Capacitors are introduced into the circuit to provide this phase shift.
  • The capacitor in series with the starting winding creates a phase difference between the currents in the starting and main windings. This phase shift results in the generation of a rotating magnetic field in the stator, facilitating motor rotation.

4. Starting Capacitor and Running Capacitor:

  • Single-phase motors often use two types of capacitors: starting capacitors and running capacitors.
    • Starting Capacitor: This capacitor is in series with the starting winding and is active only during motor startup. Its purpose is to provide the necessary phase shift to initiate motor rotation.
    • Running Capacitor: Once the motor reaches a certain speed, a centrifugal switch disconnects the starting capacitor, and a running capacitor, in parallel with the starting winding, takes over. The running capacitor continues to provide the phase shift needed for the rotating magnetic field during normal operation.

5. Improved Torque and Efficiency:

  • The introduction of capacitors in single-phase motors improves torque production, especially during startup. The rotating magnetic field generated by the phase-shifted currents enhances the motor’s starting torque, allowing it to overcome inertia and initiate rotation.
  • Capacitors also contribute to the overall efficiency of the motor by optimizing the power factor and reducing power losses.

6. Capacitor Types:

  • The choice of capacitor types depends on the motor’s design and requirements. Electrolytic capacitors are commonly used for starting capacitors, while motor-run capacitors are often made of metallized polypropylene, providing stability and durability.

7. Applications:

  • Single-phase induction motors with capacitors are widely used in various applications, including household appliances, air conditioning units, pumps, and small machinery.

8. Starting and Running Capacitor Sizes:

  • The size of the starting and running capacitors is crucial for proper motor operation. Capacitor values are selected based on the motor’s specifications, and incorrect capacitor sizing can lead to motor inefficiency, overheating, or failure.

In summary, the purpose of capacitors in a motor, especially in single-phase induction motors, is to create a phase shift between the currents in different windings. This phase shift results in the generation of a rotating magnetic field necessary for motor rotation. Capacitors contribute to improved starting torque, overall motor efficiency, and reliable operation in various applications. The proper selection and functioning of capacitors are essential for the optimal performance of single-phase induction motors.
