How do an IR transmitter and receiver work ?

Infrared (IR) transmitters and receivers are commonly used in various electronic devices for communication and control purposes. IR communication relies on the transmission of infrared light, which is not visible to the human eye but is detectable by specialized components. Here’s a detailed explanation of how an IR transmitter and receiver work:

IR Transmitter:

1. LED Emitter:

  • The IR transmitter typically employs an infrared Light Emitting Diode (IR LED) as the source of infrared radiation. This LED is specifically designed to emit light in the infrared spectrum, which is beyond the range of human vision.

2. Electrical Excitation:

  • When a voltage is applied to the IR LED, it becomes electrically excited. The excited electrons within the semiconductor material of the LED release energy in the form of photons.

3. Infrared Emission:

  • The emitted photons fall within the infrared wavelength range, typically around 850 nanometers (nm) for consumer-grade IR transmitters. This emitted infrared light is modulated to carry information by varying the intensity or frequency of the light pulses.

4. Modulation for Data Encoding:

  • In applications such as remote controls, the IR transmitter modulates the infrared light to encode digital information. Common modulation techniques include Amplitude Shift Keying (ASK) or Frequency Shift Keying (FSK), where variations in the intensity or frequency of the light correspond to binary data.

5. Focused Beam:

  • To enhance the range and efficiency of transmission, IR transmitters often use lenses to focus the emitted infrared beam. This focused beam helps ensure that the majority of the transmitted energy is directed toward the intended receiver.

IR Receiver:

1. Photodiode Sensor:

  • The IR receiver typically contains a photodiode sensor that is sensitive to infrared light. The photodiode is designed to generate an electric current when exposed to incoming infrared radiation.

2. Detection of Infrared Light:

  • When the modulated infrared light from the transmitter reaches the IR receiver, the photodiode detects the incoming radiation. The amount of current generated by the photodiode is proportional to the intensity of the received infrared light.

3. Photodiode Reverse Biasing:

  • To improve the response time and sensitivity of the photodiode, it is often operated in reverse bias. The reverse bias voltage creates a depletion region within the photodiode, facilitating a faster response to changes in incident light.

4. Demodulation for Data Extraction:

  • The received modulated infrared signal needs to be demodulated to extract the transmitted data. The demodulation process is designed to reverse the modulation applied at the transmitter, allowing the recovery of the original information.

5. Filtering and Signal Processing:

  • Infrared receivers include filters to ensure that they selectively respond to the modulated infrared signal and reject ambient light. Signal processing circuits further refine the received signal, separating it from noise and interference.

6. Output Signal:

  • The demodulated signal is then converted into a usable electrical signal, typically representing binary data. This output signal can be further processed by a microcontroller or other electronic components in the device.

7. Applications:

  • IR receivers find widespread use in applications such as remote controls for TVs, audio systems, and other electronic devices. They are also employed in proximity sensors, data communication between devices, and infrared-based data transfer protocols like Infrared Data Association (IrDA).

In summary, an IR transmitter utilizes an IR LED to emit modulated infrared light, while an IR receiver incorporates a photodiode sensor to detect and demodulate the received infrared signal. This technology enables wireless communication and control in a variety of electronic devices and applications.
